WANG Qiumu, LAN Yu, FAN Jun. Design of a low-frequency third-order super-cardioid directional source[J]. ACTA ACUSTICA, 2024, 49(1): 117-128. DOI: 10.12395/0371-0025.2022130
Citation: WANG Qiumu, LAN Yu, FAN Jun. Design of a low-frequency third-order super-cardioid directional source[J]. ACTA ACUSTICA, 2024, 49(1): 117-128. DOI: 10.12395/0371-0025.2022130
shu

Design of a low-frequency third-order super-cardioid directional source

  • 1.

    State Key Laboratory of Ocean Engineering, School of Naval Architecture, Ocean and Civil Engineering, Shanghai Jiao Tong University　Shanghai　200240

  • 2.

    Key Laboratory of Marine Intelligent Equipment and System, Ministry of Education, Shanghai Jiao Tong University　Shanghai　200240

  • 3.

    College of Underwater Acoustic Engineering, Harbin Engineering University　Harbin　150001

More Information
  • PACS:
    • 43.25  (非线性声学)
  • Received Date: November 10, 2022
  • Revised Date: February 23, 2023
  • Available Online: January 04, 2024
    Graphical Abstract
    • Abstract

  • In order to enhance the directivity gain of the primary pole in a circular array, a third-order super-cardioid sound source based on a uniform six-element circular array is proposed. The beam pattern of the sound source is investigated and analyzed by using the point source method, and an optimal scheme of the sound source is obtained. The single-sided radiation (SSR) flextensional transducer (FT) is selected as the sound source element to minimize the mutual radiation effect of the close-packed array. The acoustic radiation characteristics of the third-order super-cardioid source are studied by the finite element method. The findings demonstrate an 8 dB gain compared to the monopole sound source. A prototype is fabricated and tested. The test results confirm that the directional source exhibits a resonant frequency of 0.92 kHz with a transmitting voltage response of 139.0 dB. The −3 dB beamwidth is 56°, accompanied by all the sidelobes smaller than −15.0 dB. The feasibility of the optimized scheme is verified through the finite element calculations and measured results.

    • FullText(HTML)
    • References (18)
  • [1]
    Butler S C, Butler A L, Butler J L. Directional flextensional transducer. J. Acoust. Soc. Am., 1992; 92(5): 2977−2979 DOI: 10.1121/1.404362
    [2]
    Butler S C, Butler J L, Butler A L. A low-frequency directional flextensional transducer and line array. J. Acoust. Soc. Am., 1997; 102(1): 308−314 DOI: 10.1121/1.419609
    [3]
    Butler S C. A directional dogbone flextensional transducer. Proc. Mtgs. Acoust., 2010; 11: 1−23 DOI: 10.11990/jheu.202007105
    [4]
    Moosad K P B, Chandrashekar G, Joseph M J. Class IV flextensional transducer with a reflector. Appl. Acoust., 2011; 72: 127−131 DOI: 10.1016/j.apacoust.2010.10.003
    [5]
    Oishi T, Aronov B, Brown D A. Broadband multimode baffled piezoelectric cylindrical shell transducers. J. Acoust. Soc. Am., 2007; 121(6): 3465−3471 DOI: 10.1121/1.2722053
    [6]
    Butler J L, Butler A L, Rice J A. A tri-modal directional transducer. J. Acoust. Soc. Am., 2004; 115(2): 658−665 DOI: 10.1121/1.1639326
    [7]
    Butler J L, Butler A L, Butler S C. The modal projector. J. Acoust. Soc. Am., 2011; 129(4): 1881−1889 DOI: 10.1121/1.3559684
    [8]
    Butler J L, Sherman C H. Transducers and arrays for underwater sound. New York: ASA Press, 2016: 303
    [9]
    杜慧如, 莫喜平, 刘永平. 半空间指向性低频柱型发射换能器. 声学技术, 2019; 38(S2): 180−182
    [10]
    周天放. 共形驱动低频换能器研究. 博士学位论文, 哈尔滨: 哈尔滨工程大学, 2019: 63−91
    [11]
    李宽. 四边型弯张换能器研究. 博士学位论文, 哈尔滨: 哈尔滨工程大学, 2015: 43−63
    [12]
    莫喜平. 指向性弯张换能器. 哈尔滨工程大学学报, 2020; 41(10): 1500−1504 DOI: 10.1121/1.3526699
    [13]
    陈海洋, 向倬君, 高峰, 等. 一种宽带单指向性圆管换能器. 声学技术, 2019; 38(S2): 403−405
    [14]
    赵智勇, 王祖杰. 一种三模态指向性发射换能器设计. 水雷战与舰船防护, 2009; 17(2): 15−18
    [15]
    姚成章. 指向性圆环换能器研究. 声学技术, 2008; 27(S5): 532−533
    [16]
    Wang Q, Lan Y, Fan J. A four-element array design for the implementation of the third-order super-cardioid beam pattern. J. Acoust. Soc. Am., 2022; 152(4): 2204−2211 DOI: 10.1121/10.0014763
    [17]
    Wang Q, Fan J, Lan Y. Transducer design for low-frequency circular close-packed array and its mutual radiation analysis. J. Acoust. Soc. Am., 2022; 151(3): 2223−2237 DOI: 10.1121/10.0009579
    [18]
    COMSOL Multiphysics Reference Manual, COMSOL Multiphysics 5.6. https://comsol.com/, 2020
